Features
Amplifier
# Channels | 9.2 |
Power Watts/Ch (8 Ohms 1kHz, 2 Channels Driven, FTC) | 120, 0.08% THD |
Power Watts/Ch (6 Ohms 1kHz, 1 Channel Driven, FTC) | 250, 10% THD |
Dynamic Audio Amplification | ✓ (for Clear and Realistic Sound) |
H.C.P.S (High Current Power Supply) | ✓ |
Non-Phase Shift Amplifier | ✓ |
THX Certified | ✓ |
Continuous 6 Ohms Rated | ✓ |
Certified 4 Ohms Performance | ✓ |
Discrete Output Stage Circuitry | ✓ |
Independent Block Construction (Analog/Digital) | - |
Bi-amp Capability For Front | ✓ |
Processing
Dolby Atmos | ✓ |
32-Bit Digital Signal Processing Engine | ✓ |
Dolby Decoder | Atmos, True HD, DD Plus, Dolby Surround |
DTS:X | ✓ |
DTS Decoder | DTS:X, DTS-HD Master Audio, DTS 96/24, Neural:X, DTS-ES, DTS Express |
7.2.4ch Speaker Setup Support | ✓(requires external power amp) |
ONKYO GAME Surround Modes | ✓ (Rock, Sports, Action, RPG) |
VLSC for Noiseless Audio Processing | ✓(Front Channels) |
THX Processing Mode | ✓ |
CinemaFILTER | - |
AccuEQ Room Calibration | ✓ Advance (w/ AccuReflex) |
Direct/Pure Mode | ✓/✓ |
Advanced Music Optimizer | ✓ |
384K/32 Bit DACs | ✓ |
192K/24 Bit DACs | - |
Connectivity
Analog Audio IN | 7 (Includes 1 Phono Input) |
Phono Input | ✓ |
Digital Audio IN (OPT/COAX) | 2 / 1 |
Composite Video I/O | 2 / 0 |
Component Video I/O | 2 / 0 |
Front Panel HDMI | ✓ |
USB Input | ✓(Rear) |
HDMI I/O | 8 / 2 (Main/Zone 2/Sub) |
HDMI 4K/60 Hz- Capable HDMI Terminals | ✓ |
HDCP 2.2 Copy-Protection Compatibility | ✓ |
HDMI Support for High Dynamic Range | X (HDR10, Dolby Vision & HLG Support) |
HDMI Support for 3D, Audio Return Channel and CEC | ✓ |
BT.2020 Support | ✓ |
HDMI Support for Deep Color, x.v.Color, LipSync | ✓ |
HDMI Support for DVD-Audio, SACD, Multichannel PCM | ✓ |
Analog To HDMI Upconversion | ✓ |
1080p to 4K Upscaling | - |
4K Passthrough | ✓ |
Analog Pre-Outs | 11.2 |
Speaker A/+B | - |
Powered Zone 2 | ✓ |
Powered Zone 3 | ✓ |
Zone 2 Line Out | ✓(Analog RCA, variable volume) |
Zone 2 Video Out | ✓ (HDMI) |
Zone 2 Digital to Analog Audio Conversion | ✓(Net/SPDIF/HDMI) |
Zone 3 Line Out | ✓(Analog RCA, variable volume) |
Works with Sonos | ✓(requires FW update & Sonos Connect) |
Whole House Mode | ✓ |
FlareConnect Multi-room Audio | ✓ |
Airplay | ✓ |
Google Chromecast built-in | ✓(works with Google Assistant) |
DTS Play-Fi | ✓(via Onkyo Music Control app) |
Onkyo App Support | ✓ (Onkyo Controller and Music Control apps) |
Internet Radio Capable | ✓ (TuneIn) |
Spotify Connect Support | ✓ |
Amazon Music | ✓(accessible via Onkyo Music Control app) |
Tidal | ✓ |
Streaming Audio From PC / Network | ✓ |
Hi-Res Streaming Audio Formats | ✓ |
Streaming Audio From USB memory | ✓ |
Wireless Network | IEEE 802.11 a/b/g/n 5 Ghz / 2.4 Ghz |
Bluetooth | X (Version 4.1 + LE (Compatible Profile: A2DP v1.2, AVRCP v1.3) |
Integration Access
RS-232 | ✓ |
IR Input | ✓ |
Ethernet | ✓ |
RIHD (Remote Interactive Over HDMI) | ✓ |
12V Trigger | ✓ |
Miscellaneous
Hybrid Standby Function | ✓ |
Smart Grid-Ready | ✓ |
Auto Speaker Calibration W/Mic. | AccuEQ Advance w/AccuReflex |
OSD Out | ✓ |
Aluminum Front Panel | ✓ |
High-Grade Speaker Terminals | ✓(Banana Plug) |
Detachable AC Cord | ✓ |
Warranty | 1 YEARS |
Docs
Spec Sheet
For more technical detail, download the Spec Sheet here:
TX-RZ830 (Refurbished) Product Sheet
.
Product Manuals
Download the Product Manuals for TX-RZ830 (Refurbished) here:
TX-RZ830 (Refurbished) Owner's Manual - English
,
TX-RZ830 (Refurbished) Owner's Manual - Spanish
,
TX-RZ830 (Refurbished) Owner's Manual - French
.
Firmware Updates
- Latest firmware update instructions: TX-RZ830 (Refurbished) Firmware Update Instructions .
- Latest firmware update: TX-RZ830 (Refurbished) Firmware Update .
