TX-RZ3100
THX Certified A/V Receiver
The THX®-certified TX-RZ3100 AV receiver delivers robust high-current power and instantaneous full-scale dynamics make it the ultimate driving force for 7.2.4-channel home-theater layouts with floorstanding speakers, dual subwoofers, and in-ceiling height speakers. Packed with 140 watts per channel for ultra-clean sound, this receiver is equipped with a best-in-class, high-powered amplifier. With a 7.2.4-channel audio setup, the TX-RZ3100 is perfect for your Dolby Atmos®-ready immersive home theater system.
- THX® Select2™ Plus Certification
- Google Cast, AirPlay®, Wi-Fi®, and Bluetooth® App Streaming
- Sophisticated digital-switching technology to choose whatever you’re in the mood to hear or watch
- Dazzling 4K video distribution
- DTS Neural: X™ up mixes legacy sound for height-enabled systems
- AccuEQ Room Calibration with AccuReflex Technology
*Savings will appear in your cart upon the addition of the M-5010 and AV receiver
Features
Amplifier
| # Channels | 11.2 |
| Power Watts/Ch (8 Ohms 20-20kHz, 2 Channels Driven, FTC) | 140, 0.08% THD |
| Power Watts/Ch (6 Ohms 1kHz, 1 Channel Driven, FTC) | 200, 0.9% THD |
| Dynamic Audio Amplification | ✓ (for Clear and Realistic Sound) |
| H.C.P.S. (High Current Power Supply) | ✓ |
| Non-Phase Shift Amplifier | ✓ |
| THX Certified | ✓ |
| Continuous 6 Ohms Rated | ✓ |
| Certified 4 Ohms Performance | ✓ |
| Discrete Output Stage Circuitry | ✓ |
| Independent Block Construction (Analog/Digital) | ✓ |
| Bi-amp Capability For Front | ✓ |
Processing
| Dolby Atmos | ✓ |
| 32-Bit Digital Signal Processing Engine | ✓ |
| Dolby Decoder | Atmos, True HD, DD Plus |
| DTS:X | ✓ |
| DTS Decoder | DTS:X, DTS-HD Master Audio |
| Surround Modes | ✓ (Rock, Sports, Action, RPG) |
| VLSC for Noiseless Audio Processing | ✓ (All Channels) |
| THX Processing Mode | ✓ |
| CinemaFILTER | - |
| AccuEQ Room Calibration | ✓ (w/ AccuReflex) |
| Direct/Pure Mode | ✓ / ✓ |
| Advanced Music Optimizer | ✓ |
| 384K/32 Bit DACs | ✓ |
| 192K/24 Bit DACs | - |
Connectivity
| Analog Audio IN | 7 |
| Phono Input | ✓ |
| Digital Audio IN (OPT/COAX) | 3 / 2 |
| Composite Video I/O | 2 / 0 |
| Component Video I/O | 2 / 1 |
| Front Panel HDMI | ✓ |
| Front-Panel A/V | - |
| USB Input | ✓ (Rear) |
| HDMI I/O | 8 / 2 (Main/Zone 2/Sub) |
| HDMI 4K/60 Hz- Capable HDMI Terminals | ✓ |
| HDCP 2.2 Copy-Protection Compatibility | ✓ |
| HDMI Support for 3D, Audio Return Channel and CEC | ✓ |
| HDR10 and BT.2020 Support | ✓ |
| HDMI Support for Deep Color, x.v.Color, LipSync | ✓ |
| HDMI Support for DVD-Audio, SACD, Multichannel PCM | ✓ |
| HDMI Support for High Dynamic Range | ✓ |
| Analog To HDMI Upconversion | ✓ |
| 1080p to 4K Upscaling | ✓ |
| 4K Passthrough | ✓ |
| Analog Pre-Outs | 11.2 |
| Speaker A/+B | - |
| Powered Zone 2 | ✓ |
| Powered Zone 3 | ✓ |
| Zone 2 Line Out | ✓ |
| Zone 2 Video Out | ✓ |
| Zone 2 Digital to Analog Audio Conversion | ✓ (Net/SPDIF/HDMI) |
| Zone 3 Line Out | ✓ |
| Whole House Mode | ✓ |
| FlareConnect Multi-room Audio | ✓ |
| Airplay | ✓ |
| Chromecast built-in | ✓ |
| Supports Onkyo Controller App | ✓ |
| Internet Radio Capable | ✓ |
| Spotify Connect Support | ✓ |
| Tidal | ✓ |
| Streaming Audio From PC / Network | ✓ |
| Hi-Res Streaming Audio Formats | ✓ |
| Streaming Audio From USB memory | ✓ |
| Wireless Network | IEEE 802.11 a/b/g/n 5 Ghz / 2.4 Ghz |
| Bluetooth | ✓ (Built-in) |
Integration Access
| RS-232 | ✓ |
| IR Input | ✓ |
| Ethernet | ✓ |
| RIHD (Remote Interactive Over HDMI) | ✓ |
| 12V Trigger | ✓ |
Miscellaneous
| Hybrid Standby Function | ✓ |
| Auto Speaker Calibration W/Mic. | AccuEQ w/AccuReflex |
| OSD Out | ✓ |
| Solid Aluminum Front | ✓ |
| Transparent High-Grade Speaker Terminals | ✓ |
| Detachable AC Cord | ✓ |
| Warranty | 3 YEARS |
Specs
Amplifier Section
| All Channels | 140 W/Ch (8 Ohms, 1 kHz, 0.08% THD, 2 Channels Driven, FTC) 200 W/Ch (6 Ohms, 1 kHz, 0.9% THD, 1 Channel Driven, FTC) |
| Dynamic Power | 320 W (3 Ohms, Front) 270 W (4 Ohms, Front) 160 W (8 Ohms, Front) |
| THD+N (Total Harmonic Distortion + Noise) | 0.04% (1 kHz, 100 W) |
| Input Sensitivity and Impedance | 200 mV/82 k-ohms (Line) 3.5 mV/47 k-ohms (Phono MM) |
| Rated RCA Output Level and Impedance | 1.0 V/330 Ohms (Pre Out) 1.0 V/330 Ohms (Subwoofer Pre Out) 200 mV/1.2 k-ohms (Zone Out) 2.0 V/1.2 k-ohms (Zone Pre Out) |
| Phono Overload | 70 mV (MM, 1 kHz, 0.5%) |
| Tone Control | ±10 dB, 100 Hz (Bass) ±10 dB, 10 kHz (Treble) |
| Signal-to-Noise Ratio | 108 dB (Line, IHF-A) 90 dB (Phono, IHF-A) |
| Speaker Impedance | 4 ohms–16 ohms |
Video Section
| Video | 1.0 Vp–p/75 Ohms (Component Y) 0.7 Vp–p/75 Ohms (Component PB/CB, PR/CR) 1.0 Vp–p/75 Ohms (Composite) |
| Component Video Frequency Response | 5 Hz–100 MHz/+0 dB, -3 dB |
Tuner Section
| FM | 87.5 MHz–107.9 MHz |
| AM | 530 kHz–1,710 kHz |
| FM/AM Preset Memory | 40 stations |
General
| Power Supply | AC 120 V~, 50/60 Hz |
| Power Consumption | 340 W |
| Standby Power Consumption | 0.15 W |
| Dimensions (W x H x D) | 17 1/8" x 7 15/16" x 17 13/16" (435 x 201 x 453 mm) |
| Weight | 43.0 lbs (19.5 kg) |
Carton
| Dimensions (W x H x D) | 22 1/4" x 12 3/16" x 21 9/16" (565 x 325 x 547 mm) |
| Weight | 48.5 lbs (22.0 kg) |
UPC Code
| (B) | 889951000235 |
Docs
Product Manuals
Download the Product Manuals for TX-RZ3100 here:
TX-RZ3100 AV Receiver Owner's Manual- English
,
TX-RZ3100 AV Receiver Owner's Manual- Spanish/French
,
TX-RZ3100 AV Receiver Basic/Advanced Manual English
.
Firmware Updates
- Latest firmware update instructions: TX-RZ3100 Firmware Update Instructions .
- Latest firmware update: TX-RZ3100 Firmware Update .
