HT-S7800
The HT-S7800 package includes a powerful A/V receiver loaded with features you need for memorable entertainment every night: high-current amps, Dolby Atmos, DTS:X, 4K/60 Hz/HDR video, and FireConnect audio transmission from the receiver to an optional speaker in another room*. For music, there’s Chromecast built-in*, AirPlay, and Wi-Fi to stream albums from smartphone and PC apps.The high-quality speaker system is a snap to set up, with AccuReflex phase-aligning object-based formats for super-clear multidimensional sound.
Features
System
# Channels | 5.1.2 |
Total System Power | 1190W |
Power | 170 W/Ch (6 Ohms, 1 kHz, 0.9% THD, 1 Channel Driven, FTC); 100 W/Ch (8 Ohms, 20 Hz–20 kHz, 0.08% THD, 2 Channels Driven, FTC) |
Sub Power | 120W |
All Discrete Amplifier Circuitry | ✓ |
THX Certified | - |
Speaker A/+B | - |
Processing
Dolby Atmos Ready | ✓ |
32-Bit Digital Signal Processing Engine | AK4458 384 kHz/32-bit DAC (8 Channels x 1) |
Dolby Decoder | TrueHD, Dolby Atmos |
DTS Decoder | DTS-HD Master Audio, DTS:X |
ONKYO GAME Surround Modes | ✓ |
AccuEQ | ✓ |
Advanced Music Optimizer | ✓ (Bluetooth Included) |
Phase-Matching Bass Boost | - |
192K/24 Bit DACs | - |
Bluetooth | ✓ (Built-in) |
Connectivity
Audio I/O | 8 / 0 |
Digital Audio IN (OPT/COAX) | 2 / 1 |
Composite I/O | 2 / 0 |
USB Input | Front |
Component Video I/O | 2 |
HDMI I/O | 8 / 2 |
HDMI Support for High Dynamic Range | ✓ (Dolby Vision via firmware update) |
HDMI 2.0 4K/60 Hz- Capable HDMI Terminals | ✓ |
HDCP 2.2 Copy-Protection Compatibility | ✓ |
HDMI Support for 3D, Audio Return Channel and CEC | ✓ |
HDMI Support for Deep Color, x.v.Color, LipSync | ✓ |
HDMI Support for DVD-Audio, SACD, Multichannel PCM | ✓ |
Component Video Upconversion | ✓ |
Analog To HDMI UpConversion | ✓ |
1080p Upscaling | ✓ |
4K (up to 4096 x 2160) Upscaling | ✓ |
4K Passthrough | ✓ |
Zone 2 | Powered and Line-Out |
Airplay Ready | X Built-In |
Supports Onkyo Remote App | ✓ (iPod touch/iPhone and Android-Powered Devices) |
Internet Radio Capable | ✓ (TuneIn Radio, Pandora, Spotify,TIDAL) |
Streaming Audio From PC / Network | ✓ (DLNA, Home Media) |
Streaming Audio Formats | ✓ (MP3, WMA, WMA Lossless, FLAC, WAV, Ogg Vorbis, AAC Stereo, Apple Lossless, DSD 5.6 MHz, LPCM, Dolby TrueHD) |
Streaming Audio From USB memory | ✓ |
Wireless Network | ✓ (Wi-Fi-Certified) |
Speaker
Front / Height Speakers | 2-way (Bass Reflex)/Dolby-Atmos Enabled Full-Range (Acoustic-Suspension) |
Center Speaker | 2-way (Bass Reflex) |
Surround Speaker | Full-Range (Acoustic Suspension) |
Subwoofer | 10" Down Firing (Bass Reflex), Powered |
Cabinet Type | Wood/Gloss Finished Panels |
Miscellaneous
Pre-Pro/Learning Remote | - / - (Simple) |
On Screen Remote Programming | - |
Color-Coded Speaker Terminals | - |
Auto Speaker Calibration W/Mic. | ✓ (AccuEQ w/ AccuReflex) |
OSD Out | ✓ (Advanced "Home" GUI) |
Warranty | 2 YEARS |
Specs
Amplifier Section
All Channels | 170 W/Ch (6 Ohms, 1 kHz, 0.9% THD, 1 Channel Driven, FTC) 100 W/Ch (8 Ohms, 20 Hz–20 kHz, 0.08% THD, 2 Channels Driven, FTC) |
Dynamic Power (front) | 240 W (3 Ohms) 210 W (4 Ohms) 120 W (8 Ohms) |
THD+N (Total Harmonic Distortion + Noise) | 0.08% (20Hz-20kHz, half power) |
Input Sensitivity and Impedance | 200 mV/47 k-ohms (Line) 3.5 mV/47 k-ohms (Phono MM) |
Output Level and Impedance | 200 mV/2.3 k-ohms (Zone 2 Line Out) 1 V/470 Ohms (Subwoofer Pre Out) |
Frequency Response | 10 Hz–100 kHz/+1 dB, -3 dB (Direct mode) |
Tone Control | ±10 dB, 90 Hz (Bass) ±10 dB, 7.5 kHz (Treble) |
Signal-to-Noise Ratio | 106 dB (Line, IHF-A) 80 dB (Phono) |
Speaker Impedance | 6 Ohms–16 Ohms |
Video Section
Video | 1.0 Vp-p/75 Ohms (Component Y) 0.7 Vp-p/75 Ohms (Component PB/CB, PR/CR) 1.0 Vp-p/75 Ohms (Composite) |
Component Video Frequency Response | +0 dB, -3 dB |
Tuner Section
FM | 87.5 MHz–107.9 MHz |
AM | 530 kHz–1,710 kHz |
FM/AM Preset Memory | 40 stations |
General
Power Supply | AC 120 V, 60 Hz |
Power Consumption | 580 W |
Standby Power Consumption | 0..1 W |
Dimensions (W x H x D) | 30 3/8" x 33 11/16" x 20 1/4" (772 x 855 x 514 mm) |
Weight | 81.6 lbs. (37 kg) |
Speaker - Type
Front/Height | 2-way Bass Reflex (Front), Full-Range Acoustic Suspension (Height) |
Surround | Full-Range, Acoustic Suspension |
Subwoofer | Bass reflex, Powered |
Speaker - Drivers
Front/Height | 5" (12 cm) cone woofer 1" (2.5 cm) balanced-dome tweeter (Front), 3 1/4" (8 cm) cone |
Center | 3 1/4" (8 cm) cone woofer x 2 1" (2.5 cm) balanced-dome tweeter |
Surround | 3 1/4" (8 cm) cone |
Subwoofer | 10" (25 cm) cone |
Speaker - Frequency Response
Front/Height | 55 Hz–50 kHz / 80 Hz–20 kHz |
Center | 65 Hz-50kHz |
Surround | 80 Hz–20 kHz |
Subwoofer | 25 Hz–150 Hz |
Speaker - Output Sound Pressure Level
Front/Height | 84.5 dB/W/m (Front), 81 dB/W/m (Height) |
Center | 86 dB/W/m |
Surround | 81 dB/W/m |
Speaker - Max. Input Power
Front/Center/Surround | 130 W |
Speaker - Rated. Output Power
Subwoofer | 120 W |
Speaker- Nominal Impedance
Front/Center/Surround | 6 Ohms |
Speaker - Input Sensitivity/Impedance
Subwoofer | 540 mV/20 k-ohms |
Speaker - Dimensions (W x H x D)
Front | 6 1/8" x 18 3/8" x 7 3/16" (155 x 467 x 183 mm) |
Center | 16 9/16" x 4 1/2" x 4 11/16" (420 x 115 x 119 mm) |
Surround | 4 1/2" x 9 1/16" x 3 3/4" ( 115 x 230 x 96 mm) |
Subwoofer | 12 1/2" x 18 7/16" x 15 11/16" (317.5 x 468 x 398 mm) |
Speaker - Weight
Front | 7.9 lbs. (3.6 kg) |
Center | 5.1 lbs. (2.3 kg) |
Surround | 2.2 lbs. (1.0 kg) |
Subwoofer | 21.2 lbs. (9.6 kg) |
UPC Code
(B) | 889951000327 |
Docs
Product Manuals
Download the Product Manuals for HT-S7800 here:
HT-S7800 Owner's Manual- English
,
HT-S7800 Owner's Manual- Basic Manual, English/Spanish/French
.
Firmware Updates
- Latest firmware update instructions: HT-S7800 Firmware Update Instructions .
- Latest firmware update: HT-S7800 Firmware Update .
